C.V.A Model No 8 Single Spindle Automatic Repair Parts Catalogue PD524 EBook Instant Download

C.V.A Model No 8 Single Spindle Automatic Repair Parts Catalogue PD524 PDF

Instant Download After Purchase #Ebook ( Emailed Link )

Book Date ??

Book Number PD524

Book Size A4 With 41 Pages.

Contents

Introduction

Silent Support Bracket

Bar Feeding Unit

Headstock

Mechanical Lubrication System

Cross Slides

Turret Slide

Bed Mechanism

Backshaft

Various Covers And Guards Etc

Gear Box Castings Etc

Gear Box

Coolant Pump System

Jockey Pulleys

Safety Clutch, Cross Slide And Tool Slide Camshafts

Electrical Switch Gear

Cabiney Doors Etc

Numerical Index Of Parts

Condition. Grubby and well used but still complete and legible

Good Scan Despite Marks From Workshop

Reference 000103
